Product Description
They can process large-batch printing to maximize efficiency in many ways, delivering everything from fixed-form documents to envelopes, cards, leaflets, educational materials and more.
Product Features
Optimum output, faithful to the original
For optimal output, the EZ231 features four preset image processing modes: Line, Photo, Duo (line/ photo/shadow off) and Pencil (darker/lighter).
Optional color drum for adding color
Spot color can help documents stand out. The machine’s color drum is designed to be light, easy to set and user-friendly. It accommodates a wide variety of inks in 21 standard colors, 50 custom colors, plus special order-made colors that can give corporate logos an extra-special look.
Clearly reproduces penciled text and stamp marks
Press the pencil key for clearer output of text and lines faintly drawn by pencil as well as stamp marks.
Clearer photos
Use dot screening (fine/coarse) for clearer photo image output.
Higher quality printing with a PC
The optional RISO PC Interface Card USB2.0 enables direct printing from a PC via USB cable, which keeps the output looking more beautiful. An optional RISO Network Card enables network connection.
Friendly to the environment
The EZ231 consumes energy very sparingly, using just about 1/6th* of the power that a photocopier requires. The ink it uses is made of eco-friendly soy oil. RISO makes products that conform to the International Energy Star Program.
Full security
The EZ231 features security functions that can limit user access or secure original data in order to protect against information leakage. After printing, the master remains on the drum so that it can be printed at any time. Turn on Confidential mode, and the master on the drum is disposed of to safeguard against undesired printing of confidential documents.
RISO i Quality System
The RISO i Quality System offers a large number of quality and convenience benefits. Among them are:
- Automatic assurance of optimum print quality
- Prevention of operator error
- Warning of shortages in remaining ink/ master volume
- Minimized paper waste
Product Specification
- Master-Making/Printing Methods High-speed digital master-making/Fully automatic stencil printing
- Original Type :Book, Sheet
- Original Size :When using the Glass Platen : 50 mm x 90 mm-310 mm x 432 mmWhen using the AF-VI (option) : 100 mm x 148 mm-310 mm x 432 mm
- Original Paper Weight :When using the Glass Platen : 10 kg or less When using the AF-VI (option) : 50 gsm-128 gsm
- Scanning Area (max.)297 mm x 432 mm
- Paper Supply Capacity:1000 sheets (64 gsm)
- Print Paper Weight:Standard : 46 gsm-157 gsm When using the Card Feed Kit (option):
-A4 and smaller size (100 gsm-400 gsm) -Legal and smaller size (100 gsm-310 gsm)
-A3 and smaller size (100 gsm-210 gsm) - Image Processing Mode :Line, Photo, Duo, Pencil
- Resolution:Scanning resolution: 300 dpi x 600 dpi Print image resolution: 300 dpi x 300 dpi
- Master-making Time (for 100% reproduction ratio):Approx. 25 seconds (for A4/Portrait)
- Printing Area (max.):251 mm x 357 mm
- Print Reproduction Ratio:3 enlargements: 116%, 122%, 141%
3 reductions: 87%, 82%, 71%
Margin+: 94% - Print Speed:60 ppm-130 ppm (5 steps variable)
- Print Position Adjustment:Vertical: ± 15 mm
Horizontal: ± 10 mm - Ink Supply:Fully automatic (1,000 ml per cartridge)
- Master Supply/Disposal:Fully automatic (250 sheets per roll)
- Master Disposal Capacity:Approx. 100 sheetsan>
- User Interface:LED Panel with Progress Arrow indicators, Front Side Operation
- Power Source :EZ231E: 220 V-240 V AC,50 Hz-60 Hz
- Dimensions (W x D x H) without Stand :When in use: 1415 mm (W) x 655 mm (D) x 665 mm (H)
When in storage: 780 mm (W) x 655 mm (D) x 665 mm (H) - Weight without Stand :Approx. 100 kg
