Product Specification
- CPU : 266MHz 32Bit RISC CPU
- Template Capacity :200 templates
- Log Capacity :5,000 events
- Cards Supported : 125 KHz proximity card (AC-2100RF) /
13.56 MHz smart card (AC-2100SC) : ISO14443A mifare
fingerprint template on card - Operation Mode :Fingerprint, RF/smart card, RF/smart card + fingerprint
- LCD Display :128 × 64 graphic display LCD
- Communications :RS-485, RS-232, Wiegand In & Out
- Fingerprint Sensor :500 dpi optical sensor
- Verification(1:1) Time : < 0.5 sec
- Identification(1:N) Time : < 1 sec
- FRR / FAR :0.1% / 0.0001%
- Supply Voltage :DC 12V ~ 24V
- Operation Environment :-20 ~ 50° / Lower than 90% RH (Non-condensing)
- Dimension :92.3(W) X 170(H) X 39.5(D) mm
